86Duino EduCake
Item: 86Duino-JSK
Price: USD 49.00 (Approximately)
 NTD 1,519.00 (Exact Amount)
Stock: In Stock
Features:

● Vortex86EX Processor
● Open-Source Hardware
● Support DOS, Windows, Linux
● Arduino-Compatible IDE

Share Product:
Quantity:

Recommended Items

Total:USD (Approximately)
        (NTD )(Exact Amount)
Add to Cart

Product Information

  • Vortex86EX Processor
                - 300MHz 32-bit x86
                - 128MB DDR3
                - LAN
                - USB 2.0
                - Micro-SD
  • Open-Source Hardware
  • Support DOS, Windows, Linux
  • Arduino-Compatible IDE



EduCake is designed to be compatible with Arduino series. It is an all-in-one design with an integrated bread board. Many electronic components, sensors and accessories can be easily connected or replaced for experiment without soldering process. Its built-in special circuit protection design can prevent it from burn out due to configuration errors. You can make a module easily, quickly and also be worry free about unexpected damage caused by human factor.









Specifications

  • Processor: Vortex86EX
  • Clock Speed: 300 MHz
  • Memory: 128MB DDR3
  • Flash Memory: 8MB
  • Digital I/O Pins: 45 (of which 11 provide 32bit PWM output)
  • Analog Input Pins: 7 (11bit)
  • Operating Voltage: 5V
  • Input Voltage (recommended): 7-12V
  • DC Current per I/O Pin: 16 mA
  • DC Current for 3.3V Pin: 400 mA
