86Duino ONE Plus
Item No.: 86Duino-223-1G
Price: USD 84.00 (Approximately)
 NTD 2,688.00 (Exact Amount)
Stock: In Stock
Features:

● Vortex86EX Processor
● 1GB DDR3
● Open-Source Hardware
● Support DOS, Windows, Linux
● Arduino-Compatible IDE

Share Product:
Quantity:

Recommended Items

Total:USD (Approximately)
        (NTD )(Exact Amount)
Add to Cart

Product Information

  • Vortex86EX Processor
                - 300MHz 32-bit x86
                - 1GB DDR3
                - LAN
                - USB 2.0
                - Micro-SD
  • Open-Source Hardware
  • Support DOS, Windows, Linux
  • Arduino-Compatible IDE



86Duino is an open-source embedded platform based on Vortex86EX SoC, easy-to-use hardware and software integrated. This Arduino-compatible board can support many x86 O/S as well as those running on the original Arduino base system.

The 86Duino is a high performance and fully static 32-bit x86 processor board compatible with Windows OS, Linux and most popular 32-bit RTOS. It integrates PCIE bus, DDR3, ROM controller, xISA, I2C, SPI, IPC (Internal Peripheral Controllers with DMA and interrupt timer/counter included), Fast Ethernet, FIFO UART, USB2.0 and SD/SATA controller within a single package to form a system-on-a-chip (SOC).

86Duino provides an ideal solution for the Arduino and embedded system with desired performance.











Specifications

  • Processor: Vortex86EX
  • Clock Speed: 300 MHz
  • Memory: 1GB DDR3
  • Flash Memory: 8MB
  • Digital I/O Pins: 45 (of which 11 provide 32bit PWM output)
  • Analog Input Pins: 7 (11bit)
  • Operating Voltage: 5V
  • Input Voltage (recommended): 6-24V
  • DC Current per I/O Pin: 16 mA
  • DC Current for 3.3V Pin: 400 mA
